主要技術參數Main technical parameters

項目 Project

單位Unit

LX-2012

LX-2016

工作臺面積（長度x寬度）Table area (length x width)

mm

2000x1000

2000x1600

工作臺承重Table maximum bearing

mm

≤5000

≤6000

T型槽（槽數x槽寬x節距）T slot (number x width x distance)

mm

5-22x180

7-22x190

門寬Door width

mm

1500

1900

X軸/Y軸/Z軸行程

X axis /Y axis /Z axis travel

mm

2200/1200/800

2200/1600/800

主軸端面至工作臺面的距離Distance from spindle to table

mm

150-950

150-950

數控系統CNC system

選配Select

選配Select

X軸/Y軸/Z軸快速移動

X axis /Y axis /Z axis rapid movement

m/min

10/10/8

10/10/8

切削進給速度

Maximum cutting feed rate

m/min

≤6

≤6

標準刀具數量

Standard tool quantity

把handle

BT50-24

BT50-24

刀具直徑/長度Maximum tool diameter / length

mm

Φ≤110/300

Φ≤110/300

刀具交換方式

Tool exchange mode

氣動Pneumatic

氣動Pneumatic

刀具重量Max tool weight

kg

≤18

≤18

定位精度positioning accuracy

mm

0.025

0.025

重復定位精度Repeat positioning accuracy

mm

0.020

0.020

導軌形式Type of guide

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

主軸規格Spindle specifications

mm

BT50/150

BT50/150

轉速Maximum speed

rpm

≤6000

≤6000

主軸馬達功率

Spindle motor power

kw

15/18.5

15/18.5

空氣需求Air demand

Kg/cm²

≥6

≥6

氣源流量Gas flow

m³/min

≥0.5

≥0.5

機器重量Machine weight

Kg

15000

16000

外形尺寸（長x寬x高）Overall dimensions (length x width x height)

mm

6000x2940x4200

6000x3500x4200

主要技術參數Main technical parameters

項目 Project

單位Unit

LX-2512

LX-2516

工作臺面積（長度x寬度）Table area (length x width)

mm

2500x1200

2500x1600

工作臺承重Table maximum bearing

mm

≤6500

≤7500

T型槽（槽數x槽寬x節距）T slot (number x width x distance)

mm

5-22x180

7-22x190

門寬Door width

mm

1500

1900

X軸/Y軸/Z軸行程

X axis /Y axis /Z axis travel

mm

2700/1200/800

2700/1600/800

主軸端面至工作臺面的距離Distance from spindle to table

mm

150-950

150-950

數控系統CNC system

選配Select

選配Select

X軸/Y軸/Z軸快速移動

X axis /Y axis /Z axis rapid movement

m/min

8/10/8

8/10/8

切削進給速度

Maximum cutting feed rate

m/min

≤6

≤6

標準刀具數量

Standard tool quantity

把handle

BT50-24

BT50-24

刀具直徑/長度Maximum tool diameter / length

mm

Φ≤110/300

Φ≤110/300

刀具交換方式

Tool exchange mode

氣動Pneumatic

氣動Pneumatic

刀具重量Max tool weight

kg

≤18

≤18

定位精度positioning accuracy

mm

0.025

0.025

重復定位精度Repeat positioning accuracy

mm

0.020

0.020

導軌形式Type of guide

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

主軸規格

Spindle specifications

mm

BT50/150

BT50/150

轉速Maximum speed

rpm

≤6000

≤6000

主軸馬達功率

Spindle motor power

kw

15/18.5

15/18.5

空氣需求Air demand

Kg/cm²

≥6

≥6

氣源流量Gas flow

m³/min

≥0.5

≥0.5

機器重量Machine weight

Kg

18000

19000

外形尺寸（長x寬x高）Overall dimensions (length x width x height)

mm

6700x2940x4200

6700x3500x4200

主要技術參數Main technical parameters

項目 Project

單位Unit

LX-3012

LX-3016

工作臺面積（長度x寬度）Table area (length x width)

mm

3000x1200

3000x1600

工作臺承重

Table maximum bearing

mm

≤8000

≤9000

T型槽（槽數x槽寬x節距）T slot (number x width x distance)

mm

5-22x180

7-22x190

門寬Door width

mm

1500

1900

X軸/Y軸/Z軸行程

X axis /Y axis /Z axis travel

mm

3200/1200/800

3200/1600/800

主軸端面至工作臺面的距離Distance from spindle to table

mm

150-950

150-950

數控系統CNC system

選配Select

選配Select

X軸/Y軸/Z軸快速移動

X axis /Y axis /Z axis rapid movement

m/min

8/10/8

8/10/8

切削進給速度

Maximum cutting feed rate

m/min

≤6

≤6

標準刀具數量

Standard tool quantity

把handle

BT50-24

BT50-24

刀具直徑/長度Maximum tool diameter / length

mm

Φ≤110/300

Φ≤110/300

刀具交換方式

Tool exchange mode

氣動Pneumatic

氣動Pneumatic

刀具重量Max tool weight

kg

≤18

≤18

定位精度positioning accuracy

mm

0.025

0.025

重復定位精度

Repeat positioning accuracy

mm

0.020

0.020

導軌形式Type of guide

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

主軸規格

Spindle specifications

mm

BT50/190

BT50/190

轉速Maximum speed

rpm

≤4000

≤4000

主軸馬達功率

Spindle motor power

kw

15/18.5

22/26

空氣需求Air demand

Kg/cm²

≥6

≥6

氣源流量Gas flow

m³/min

≥0.5

≥0.5

機器重量Machine weight

Kg

20000

24000

外形尺寸（長x寬x高）Overall dimensions (length x width x height)

mm

8000x2940x4200

8000x3500x4300

主要技術參數Main technical parameters

項目 Project

單位Unit

LX-4012

LX-4016

工作臺面積（長度x寬度）Table area (length x width)

mm

4000x1200

4000x1600

工作臺承重Table maximum bearing

mm

≤12000

≤13000

T型槽（槽數x槽寬x節距）T slot (number x width x distance)

mm

7-22x170

7-22x190

門寬Door width

mm

1500

1900

X軸/Y軸/Z軸行程

X axis /Y axis /Z axis travel

mm

4200/1200/800

4200/1600/800

主軸端面至工作臺面的距離Distance from spindle to table

mm

150-950

150-950

數控系統CNC system

選配Select

選配Select

X軸/Y軸/Z軸快速移動

X axis /Y axis /Z axis rapid movement

m/min

8/10/8

8/10/8

最大切削進給速度

Maximum cutting feed rate

m/min

5

5

標準刀具數量

Standard tool quantity

把handle

BT50-24

BT50-24

刀具直徑/長度Maximum tool diameter / length

mm

Φ≤110/300

Φ≤110/300

刀具交換方式

Tool exchange mode

氣動Pneumatic

氣動Pneumatic

刀具重量Max tool weight

kg

≤18

≤18

定位精度positioning accuracy

mm

0.025

0.025

重復定位精度

Repeat positioning accuracy

mm

0.020

0.020

導軌形式Type of guide

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

X.Y線軌 Z硬軌

X.Y wire rail Z hard rail

主軸規格

Spindle specifications

mm

BT50/190

BT50/190

最高轉速Maximum speed

rpm

4000

4000

主軸馬達功率

Spindle motor power

kw

22/26

22/26

空氣需求Air demand

Kg/cm²

≥6

≥6

氣源流量Gas flow

m³/min

≥0.5

≥0.5

機器重量Machine weight

Kg

26000

30000

外形尺寸（長x寬x高）Overall dimensions (length x width x height)

mm

10000x3100x4300

10000x3600x4300
